Construction:
Aluminum foil | 7 microns |
Tri-way fiberglass scrim | 16*12threads/10cm*10cm |
Adhesive | Polyethylene |
Kraft paper | 60gsm(Natural) |
Typical Physical Properties:
Properties | Unit | Value | Test Method |
Basic Weight | gsm | 125 | ASTM D646 |
Tensile Strength : M. D. X. D. | N/25mm | 127.40 95.30 | ASTM D828 |
Burst Strength | N | 156.4 | ASTM D774 |
Reflective of Foil Surface | % | 95 | ------------ |
Temp. Resistance | -26℃ to 66 ℃ | No Delamination | ASTM C 1263 |
Water vapor | ng/N.s | ≦5.75 | ASTM E-96 |
Dimension:
(1) Roll width: 1.00m,1.2m,1.25m1.30m,1.35m
(2) Roll Length: 50m, 100m, 200m, 500m, 1000m, or upon your request.
(3) Core I.D.: 3"(76mm+/-1)
Base on order,special sizes are also available.
Remarks:
(1) The data above are typical results and subject to change without notice
(2) Tolerance: Weight and Thickness:±10%; Width ±3mm Length:±0.5%
(3) The products should be stores at room temperature, kept from wet and kept away heat source.
(4) The users should take test and do trial-application on the above products before coming into application so as to witness and ensure suitability for their special purpose and technique.
